Produktblad
Management features
Switch typ
hanterad
Anslutningar
Konsolport
RJ-45/USB Type-C
Antal grundläggande RJ-45 Ethernet-portar
48
Typ av grundläggande RJ-45 Ethernet-portar
5G Ethernet (100/1000/5000)
Antal SFP-modulplatser
8
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.3af
Data transmission
Switch kapacitet
880 Gbit/s
Paketbuffertminne
16 MB
Latens (1 Gbps)
4,24 ps
Latens (10 Gbps)
1,5 ps
Genomströmning
654 Mpps
Design
Staplingsbar
Prestanda
Internminne
8000 MB
Flashminne
32000 MB
Processorfrekvens
1800 MHz
Minnestyp
DDR4-SDRAM
Processor
ARM Cortex-A72
Inbyggd processor
Fysisk stackning (enheter)
10
Strömtillförsel
AC-inspänning
100 - 240 V
Meddelane om effektförbrukning
With JL086A PSU: Idle: 133W 100% Traffic Rate: 199W With JL087A PSU: Idle: 138W 100% Traffic Rate: 193W With JL670A PSU: Idle: 140W 100% Traffic Rate: 201W
Strömförsörjning ingår
Strömkälla
AC
Notering för strömförsörjning
2 field‐replaceable, hot‐swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A and JL670A.
Power over Ethernet (PoE)
Power over Ethernet (PoE)-effekt per port
90 W
Total Power over Ethernet (PoE)-budget
2880 W
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Vikt (imperial)
6,71 kg (14.8 lbs)
Dimension (B x D x H) (imperial)
43,9 x 442 x 386,1 mm (1.73 x 17.4 x 15.2")
Fläkt
Switch has two fan tray slots and comes with two fan trays installed. Minimum two fan trays required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Prestandahantering
Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Minne och processor
Quad Core Arm Cortex A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 16 MB Shared Packet Buffer Memory
Externa anslutningar
48 x HPE Smart Rate 100 M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port 4 x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W) 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM port
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Bredd
44 mm
Djup
442 mm
Höjd
385 mm
Vikt
6,71 kg
|
