Produktblad
Management features
Switch-lager
L3
Switch typ
hanterad
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.3af
Data transmission
Genomströmning
20000 Mpps
Switch kapacitet
28000 Gbit/s
Design
Kompatibla produkter
R0X27C, R0X38C, R0X39C, R0X40C, R0X41C, R0X42C, R0X43C
Produktens färg
Svart
Staplingsbar
Prestanda
Internminne
8000 MB
Flashminne
32000 MB
Processorfrekvens
1800 MHz
Minnestyp
DDR4-SDRAM
Inbyggd processor
Strömtillförsel
AC-inspänning
200 - 240 V
Växelström Frekvens
50/60 hz
Meddelane om effektförbrukning
R0X35A PSU: 1800W at 200–240 VAC, 1100W at 110–127 VAC R0X36A PSU: 3000W at 200–240 VAC, 1500W at 110–127 VAC
Strömkälla
AC
Notering för strömförsörjning
Power supply units are not included; order separately. Supports four modular front‐serviceable power supplies with removable rear‐serviceable power cord inlet adapters. Supported power supplies: R0X35A, R0X36A. PoE available will be dependent on the number of management modules, line cards, fan trays and the number of power supplies used. Power supplies not included; order separately.
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Vikt (imperial)
53,6 kg (118.2 lbs)
Funktioner för hanterbarhet
Aruba AirWave, Aruba Central Network Management, Aruba NetEdit, Aruba CX Mobile App, Command-line interface, SNMP v2c/v3, RMON
Prestandahantering
1 x RJ‐45 console port 1 x USB‐C console port 1 x OOBM port 1 x USB Type-A host port HPE Aruba Networking Management Software (AirWave) HPE Aruba Networking Central HPE Aruba Networking Switch Multi-Edit Software HPE Aruba Networking CX Mobile App Command-line interface SNMP v2c/v3 RMON
Latens
1G: 5.32 μSec 10G: 1.48 μSec 25G: 2.78 μSec 40G: 1.31 μSec 100G: 1.42 μSec
Minne och processor
CPU Management Module: Quad-core Arm Cortex A72 at 1.8 GHz Line Cards: Dual-core Arm Cortex A72 at 1.8 GHz (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: Quad-core Arm Cortex A72 at 1.8 GHz (R0X38C‐R0X45C, S0E48A, S1T83A) Memory and flash Management Module: 16 GB DDR4 ECC memory: 32 GB eMMC Flash memory Line Cards: 4 GB DDR4 memory (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: 8 GB DDR4 memory (R0X38C‐R0X45C, S0E48A, S1T83A)
Externa anslutningar
High speed, non-blocking 1/10/25/40/50/100GbE ports 10 I/O module slots maximum depending on model
Fläkt
Four field replaceable system fan trays
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Vikt
53,5 kg
Bredd
528,8 mm
Djup
442,6 mm
Höjd
528,8 mm
|
