Produktblad
Egenskaper
Datahastighet för Ethernet-LAN
2500,5000 Mbit/s
Modulator
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Frekvensband
20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps
Maximal dataöverföringshastighet
2400 Mbit/s
2,4 GHz
5 GHz
GPS
GLONASS
MIMO
Kommunikationsstandarder
IEEE 802.11ax, IEEE 802.11mc
Bluetooth
Bluetooth-version
5.0
6 Ghz
MACsec-stöd
Bevakning
Kryptering/säkerhet
WPA, WPA2, WPA3
Management features
Hantering av accesspunkt
On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Anslutningar
Antal LAN (RJ-45) anslutningar
2
Antal USB 2.0 anslutningar
1
Strömtillförsel
Strömförsörjning via Ethernet (PoE) stöd
Design
Produktens färg
Vit
placering
Tak
Rekommenderad användning
inomhus
Antenn
Antenn ökningsnivå (max)
7 dBi
Antenntyp
Intern
Antennens riktningstyp
Rundstrålande
Antennfunktioner
Integrerad antenn
Prestanda
Kompatibla operativsystem
AP-634 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-634 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.03 AP-635: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.9.0.0, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-634 is only supported on HPE Aruba Networking OS 10.7.0.0 and later deployments and HPE Aruba Networking OS 8.12.0.0 and later deployments that include a HPE Aruba Networking Mobility Conductor. Standard power operation is not supported on Instant OS deployments or 8.x HPE Aruba Networking OS deployments without a HPE Aruba Networking Mobility Conductor.
Certifikat
Certifiering
UL2043 plenum rating Wi‐Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5)
Certifikat för överensstämmelse
Federal Communications Commission (FCC), ISED, CE, Elektromagnetisk kompatibilitet (EMC), Direktivet om lågspänning (LVD)
Vikt & dimension
Vikt
1,3 kg
Bredd
220 mm
Djup
220 mm
Höjd
51 mm
Övrigt
Montage
A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately).
Vikt (imperial)
1,3 kg (2.86 lbs)
Externa anslutningar
E0, E1: Two Ethernet wired network ports (RJ-45); Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX; 2.5Gbps speed complies with NBase-T and 802.3bz specifications; POE-PD: 48Vdc (nominal) 802.3af/at/bt POE (class 3 or higher); 802.3az Energy Efficient Ethernet (EEE)
Miljökrav
Fuktighet (förvaring)
10 - 100%
Temperaturintervall (förvaring)
-25 - 55 ° C
Intervall för relativ operativ luftfuktighet
5 - 95%
Temperatur vid drift
0 - 50 ° C
|
