Produktblad
Egenskaper
Frekvensband
20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 7.8 Gbps
Maximal dataöverföringshastighet
7800 Mbit/s
Frekvensomfång
160 MHz
Datahastighet för Ethernet-LAN
5000 Mbit/s
Stöd för garanterad tjänstekvalitet (QoS)
Spatiala strömmar
4
Dataöverföringshastighet
7800 Mbit/s
Bluetooth
Bluetooth-version
5.0
6 Ghz
Bluetooth Low Energy (BLE)
2,4 GHz
5 GHz
Wi-Fi Multimedia (WMM)/(WME)
Kommunikationsstandarder
IEEE 802.11ax, IEEE 802.11mc
MIMO
Bandstyrd
MACsec-stöd
Protokoll
Stöd för nätverksprotokoll
IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6E), IEEE 802.15.4 (Zigbee), BLE 5.0, WPA/WPA2/WPA3
Stödda protokoll
802.11a/b/g/n/ac/ax (Wi‑Fi 6E); WPA/WPA2/WPA3 (Enterprise with CNSA option, Personal SAE); Enhanced Open (OWE); WMM, WMM-PS; Wi‑Fi Agile Multiband; BLE 5.0; Zigbee (802.15.4); 802.11 FTM
Management features
Hantering av accesspunkt
On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Molnhanterat
Anslutningar
Likströmsingång
Antal LAN (RJ-45) anslutningar
2
Antal USB 2.0 anslutningar
1
Antal interna RJ-45-portar
2
Strömtillförsel
Strömförsörjning via Ethernet (PoE) stöd
Design
Produktvikt (oz)
Typ av kabellåsanslutning
Kensington
Rekommenderad användning
inomhus
Antenn
Antennanslutning
RP-SMA
Antenntyp
Extern
Antennfunktioner
Avtagbar antenn
Antenner mängd
8
Prestanda
Kompatibla operativsystem
AP-654 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-654 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.01 AP-655: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.10.0.1, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-654 is only supported on HPE Aruba Networking Wireless Operating System software release 10.7.0.0 and later deployments and HPE Aruba Networking Wireless Operating System software release 8.12.0.0 and later deployments that include a HPE Aruba Networking Virtual Mobility Conductor. SP operation is not supported on Instant OS deployments or 8.x OS deployments without a HPE Aruba Networking Virtual Mobility Conductor.
Certifikat
Certifiering
UL2043 plenum rating Wi‐Fi Alliance Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2, and WPA3 -Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 6)
Certifikat för överensstämmelse
Federal Communications Commission (FCC), ISED, CE, Direktivet om lågspänning (LVD)
Vikt & dimension
Höjd
260 mm
Bredd
260 mm
Djup
56 mm
Vikt
1,8 kg
Övrigt
Externa anslutningar
Ports E0, E1: Ethernet wired network ports (RJ-45) U0: USB 2.0 host interface (Type A connector) Kensington security slot Serial console interface (proprietary, micro B USB physical jack)
Vikt (imperial)
1,8 kg (3.97 lbs)
|
Tillbehör |
