Produktblad
Management features
Switch typ
hanterad
Switch-lager
L3
Stöd för garanterad tjänstekvalitet (QoS)
Anslutningar
Konsolport
RJ-45/USB Type-C
Antal grundläggande RJ-45 Ethernet-portar
45
Typ av grundläggande RJ-45 Ethernet-portar
10G Ethernet (100/1000/10000)
Antal QSFP28-ingångar
4
USB C-typ, antal portar
1
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Data transmission
Switch kapacitet
1760 Gbit/s
Paketbuffertminne
32 MB
Genomströmning
1310 Mpps
Protokoll
Router-protokoll
BGP, OSPF
Design
Rackmontering
Staplingsbar
Produktens färg
Svart
Prestanda
Fysisk stackning (enheter)
10
Inbyggd processor
Internminne
8000 MB
Flashminne
32000 MB
Processorfrekvens
1800 MHz
Minnestyp
DDR4-SDRAM
Strömtillförsel
AC-inspänning
100 - 240 V
Meddelane om effektförbrukning
With single JL086A PSU: Idle: 207W 100% Traffic Rate: 283W With single JL087A PSU: Idle: 208W 100% Traffic Rate: 282W With single JL670A PSU: Idle: 211W 100% Traffic Rate: 283W
Strömförsörjning ingår
Notering för strömförsörjning
2 field-replaceable, hot-swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A, JL670A and JL758A.
Strömkälla
PoE
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Total Power over Ethernet (PoE)-budget
2640 W
Power over Ethernet (PoE)-effekt per port
90 W
Övrigt
Prestandahantering
Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Minne och processor
Quad Core Arm Cortex A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 32 MB Shared Packet Buffer Memory
Externa anslutningar
48x HPE Smart Rate 100M [5]/1G/2.5G/5G/10G BaseT Class 8 PoE ports supporting up to 90W per port (MACsec) 4x 10G/25G/40G/100G QSFP/QSFP28 ports (MACsec) Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 90W) 1x USB-C console port 1x USB Type-A host port 1x OOBM port 1x RJ-45 console port [5] 100M use on HPE Smart Rate ports is limited to full‐duplex only. For 100M half‐duplex support, use 1G ports on other models.
Vikt (imperial)
6,02 kg (13.3 lbs)
Fläkt
Switch has three fan tray slots and comes with three JL714A fan trays installed. Minimum three fan trays required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Bredd
44 mm
Djup
442 mm
Höjd
44 mm
Vikt
6,02 kg
Logistikdata
Farligt gods, klass
Klass 8
|
