Produktblad
Management features
Switch-lager
L3
Switch typ
hanterad
Anslutningar
Konsolport
USB
Antal grundläggande RJ-45 Ethernet-portar
48
Typ av grundläggande RJ-45 Ethernet-portar
10G Ethernet (100/1000/10000)
Antal installerade SFP-moduler
0
Antal installerade SFP+-moduler
0
Antal SFP-modulplatser
4
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Data transmission
Latens (1 Gbps)
4,24 ps
Latens (10 Gbps)
1,5 ps
Genomströmning
654 Mpps
Switch kapacitet
880 Gbit/s
Design
Antal fläktar
2 fläkt/-ar
Rackmontering
Formfaktor
1U
Staplingsbar
Produktens färg
Svart
Prestanda
Processor
ARM Cortex-A9
Inbyggd processor
Processortillverkare
Arm
Fysisk stackning (enheter)
10
Flashminne
32000 MB
Processorfrekvens
1800 MHz
Minnestyp
DDR4-SDRAM
Internminne
8000 MB
Strömtillförsel
Strömkälla
AC/PoE
Notering för strömförsörjning
2 field-replaceable, hot-swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL085A and JL757A.
Strömförsörjning ingår
Meddelane om effektförbrukning
With JL086A PSU: Idle: 133W 100% Traffic Rate: 199W With JL087A PSU: Idle: 138W 100% Traffic Rate: 193W With JL670A PSU: Idle: 140W 100% Traffic Rate: 201W
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Total Power over Ethernet (PoE)-budget
2880 W
Övrigt
Vikt (imperial)
6,02 kg (13.3 lbs)
Prestandahantering
Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Minne och processor
CPU: Dual-core Arm Cortex-A9 @ 1.8GHz Memory: 8 GB DDR4, 32 GB eMMC Flash: 8 MB, 16 MB, or 32 MB, depending on model and configuration
Externa anslutningar
48x HPE Smart Rate 100M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port 4x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W) 1x USB-C console port 1x USB Type-A host port 1x OOBM port [5] 100M use on HPE Smart Rate ports is limited to full‐duplex only. For 100M half‐duplex support, use 1G ports on other models. [4] 450G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which require QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports.
Fläkt
Switch has two fan tray slots and comes with two fan trays installed. Minimum two fan trays required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Vikt
6,02 kg
Bredd
44 mm
Djup
442 mm
|
