hanterad

RJ-45/USB Type-C

32

5G Ethernet (100/1000/5000)

IEEE 802.3af

780 Gbit/s

8 MB

5,5 ps

2,3 ps

580 Mpps

Svart

10

8000 MB

32000 MB

1800 MHz

DDR4-SDRAM

With JL670A PSU: Idle: 106W 100% Traffic Rate: 159W With JL758A PSU: Idle: 118W 100% Traffic Rate: 156W

AC

2 field-replaceable, hot-swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A, JL670A and JL758A.

100 - 240 V

2880 W

6,02 kg (13.3 lbs)

Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software

Less than 5 μs 10 Gbps LRM: 2.3 μs 10 Gbps dual mode ports: 5.5 μs 25 Gbps: 3.5 μs

CPU: Dual-core Arm Cortex-A9 @ 1.8GHz Memory: 8 GB DDR4, 32 GB eMMC Flash: 8 MB, 16 MB, or 32 MB, depending on model and configuration

32x HPE Smart Rate 1G/2.5G/5G Base-T ( configuration can be changed to 16x HPE Smart Rate 1G/2.5G/5G Base-T and 8x HPE Smart Rate 1G/2.5G/5G/10G Base-T ports) Class 8 PoE ports supporting up to 90W POE per port and 8x 1G/10G SFP+ (LRM) ports 2x 10G/25G/50G [4] SFP ports 2x 10G/25G SFP ports (MACsec) Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 90W) 1x USB-C console port 1x USB Type-A host port 1x OOBM port 1x RJ-45 console Port 1x Bluetooth dongle to be used with CX Mobile App [4] 450G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which require QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports.

Switch has two fan tray slots and comes with two fan trays installed. Minimum two fan trays required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.

0 - 45 ° C

44 mm

442 mm

6,02 kg
