Produktblad
Management features
Molnhanterat
CLI (Configuring Location Settings)
Switch typ
hanterad
Switch-lager
L2/L3
Stöd för garanterad tjänstekvalitet (QoS)
Systemhändelselogg
MIB stödd
RFC 1155 SMI RFC 1157 SNMPv1 RFC 1212, RFC 1213, RFC 1215 MIB-II, Ethernet-Like MIB and TRAPs RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 1657 BGP-4 MIB RFC 1724 RIPv2 MIB RFC 1850 OSPFv2 MIB RFC 1905 RFC 1907 SNMP v2c, SMIv2 and Revised MIB-II RFC 2011 SNMPv2 for Internet Protocol using SMIv2 RFC 2012 SNMPv2 for transmission control protocol using SMIv2 RFC 2013 SNMPv2 for user datagram protocol suing SMIv2 RFC 2096 IPv4 Forwarding Table MIB RFC 2287 System Application Packages MIB RFC 2570–2575 SNMPv3, user based security, encryption, and authentication RFC 2576 Coexistence between SNMP Version 1, Version 2 and Version 3 RFC 2578 SNMP Structure of Management Information MIB RFC 2579 SNMP Textual Conventions for SMIv2 RFC 2665 Ethernet-like interface MIB RFC 2787 VRRP MIB RFC 2819 RMON MIB RFC 2863 Interface Group MIB RFC 2863 Interface MIB RFC 2922 LLDP MIB RFC 2925 Ping/Traceroute MIB RFC 2932 IPv4 Multicast MIB RFC 3413 SNMP Application MIB RFC 3414 User-based Security model for SNMPv3 RFC 3415 View-based Access Control Model for SNMP RFC 3621 PoE-MIB (PoE switches only) RFC 4188 STP and Extensions MIB RFC 4363 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and VLAN extensions RFC 5643 OSPF v3 MIB support Draft – blumenthal – aes – usm - 08 Draft – reeder - snmpv3 – usm - 3desede -00 Draft-ietf-bfd-mib-02.txt Draft-ietf-idmr-igmp-mib-13 Draft-ietf-idmr-pim-mib-09 Draft-ietf-idr-bgp4-mibv2-02.txt – Enhanced BGP-4 MIB Draft-ietf-isis-wg-mib-07
ARP-inspektion
Anslutningar
Konsolport
RJ-45
Antal grundläggande RJ-45 Ethernet-portar
24
Typ av grundläggande RJ-45 Ethernet-portar
Gigabit Ethernet (10/100/1000)
Antal SFP+-modulplatser
4
Antal Uplink-portar
2
Nätverk
VLAN-funktioner
MVRP, Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN
Neighbor Discovery Protocol (ND) poster
3000
Address Resolution Protocol (ARP) poster (max)
4096
Policybaserad routing
Stöd för automatisk inlärning av MAC-adresser
Ethernet Ring Protection Switching (ERPS)
Kommunikationsstandarder
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Datahastighet för Ethernet-LAN
10,100,1000 Mbit/s
VLAN-stöd
Koppar Ethernet-kablar teknik
10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-X
Flödeskontroll
IP-routning
Auto MDI / MDI-X
Antal VLAN
1020
STP (Spanning Tree Protocol)
10G stöd
Portspegling
Länkaggregering
Data transmission
Jumbo Frames stöd
Lagra-och-vidarebefordra
Adresstabellstorlek
32000 poster
Switch kapacitet
64 Gbit/s
Genomströmning
95 Mpps
Jumboramar
9216
Statisk routning
Bevakning
Lösenordsskydd
Ständig MAC-inlärning (Sticky MAC)
Autentiseringstyp
AAA, IEEE 802.1x, RADIUS, TACACS+
Algoritmer för schemaläggning av köer
SP, Weighted random early detection (WRED)
Autentisering
MAC-baserad auktorisering
Åtkomstkontrollista (ACL)
Kryptering/säkerhet
802.1x RADIUS, EAP, HTTPS, MD5, PEAP, SNMP, SNMPv2, SNMPv3, SSH-2, TLS, TTLS
IGMP-snooping
DHCP-funktioner
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping
Multicast-funktioner
IPv4 multicast-poster
3200
IPv6 multicast-poster
1650
Multicast listener discovery (MLD)-snooping
Yes
Multicast-stöd
Protokoll
VRRP (Virtual Router Redundancy Protocol)
Router-protokoll
BGP, IS-IS, OSPF, OSPFv3, RIP-1, RIP-2, RIPng
IPSG (IP Source Guard)
Design
Produktens färg
Grå
Formfaktor
1U
Rackmontering
LED-indikatorer
Återställningsknapp
Temperatursensor
Prestanda
Minnestyp
DRAM
Internminne
4000 MB
RFC-lista
RFC 783 TFTP RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 854 Telnet client and server RFC 894 IP over Ethernet RFC 903 RARP RFC 906 TFTP Bootstrap RFC 951, 1542 BootP RFC 1027 Proxy ARP RFC 1058 RIP v1 RFC 1112 IGMP v1 RFC 1122 Host Requirements RFC 1195 Use of OSI IS-IS for Routing in TCP/IP and Dual Environments (TCP/IP transport only) RFC 1256 IPv4 ICMP Router Discovery (IRDP) RFC 1492 TACACS+RFC 1519 CIDR RFC 1587 OSPF NSSA Option RFC 1591 DNS RFC 1812 Requirements for IPv4 Routers RFC 1981 Path MTU Discovery for IPv6 RFC 2030 SNTP, Simple Network Time Protocol RFC 2068 HTTP server RFC 2080 RIPng for IPv6 RFC 2131 BOOTP/DHCP relay agent and DHCP server RFC 2138 RADIUS Authentication RFC 2139 RADIUS Accounting RFC 2154 OSPF w/Digital Signatures (password, MD-5) RFC 2236 IGMP v2 RFC 2267 Network Ingress Filtering RFC 2328 OSPF v2 (edge-mode) RFC 2338 VRRP RFC 2362 PIM-SM (edge-mode) RFC 2370 OSPF Opaque LSA Option RFC 2453 RIP v2 RFC 2460 Internet Protocol, Version 6 (IPv6) Specification RFC 2461 Neighbor Discovery for IP Version 6 (IPv6) RFC 2463 Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification RFC 2464 Transmission of IPv6 Packets over Ethernet Networks RFC 2474 DiffServ Precedence, including 12 queues/port RFC 2475 DiffServ Core and Edge Router Functions RFC 2526 Reserved IPv6 Subnet Anycast Addresses RFC 2597 DiffServ Assured Forwarding (AF) RFC 2598 DiffServ Expedited Forwarding (EF) RFC 2740 OSPF for IPv6 RFC 2925 MIB for Remote Ping, Trace RFC 3176 sFlow RFC 3376 IGMP v3 RFC 3484 Default Address Selection for Internet Protocol Version 6 (IPv6) RFC 3513 Internet Protocol Version 6 (IPv6) Addressing Architecture RFC 3569 draft-ietf-ssm-arch-06.txt PIM-SSM PIM Source Specific Multicast RFC 3579 RADIUS EAP support for 802.1x RFC 6614 RadSec RFC 3618 Multicast Source Discovery Protocol (MSDP) RFC 3623 OSPF Graceful Restart RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers RFC 4291 IPv6 Addressing Architecture RFC 4443 ICMPv6 for the IPv6 Specification RFC 4541 IBMP and MLD snooping services RFC 4552 OSPFv3 Authentication RFC 4861 Neighbor Discovery for IPv6 RFC 4862 IPv6 Stateless Address Autoconfiguration RFC 4915 MT-OSPF RFC 5095 Deprecation of Type 0 Routing Headers RFC 5176 Dynamic Authorization Extensions to RADIUS RFC 5798 VRRPv3 for IPv6 Draft-ietf-bfd-base-05.txt Bidirectional Forwarding Detection Draft-ietf-idr-restart-10.txt Graceful Restart Mechanism Draft-ietf-isis-restart-02 Restart Signaling for IS-IS Draft-ietf-isis-wg-multi-topology-11 Multi Topology (MT) Routing in IS-IS for BGP Internet draft-ietf-isis-ipv6-06.txt, Routing IPv6 with IS-IS LLDP Media Endpoint Discovery (LLDP-MED), ANSI/ TIA-1057, draft 08 PIM-DM Draft IETF PIM Dense Mode draft-ietf-idmrpimdm-05.txt, draft-ietf-pim-dm-new-v2-04.txt
Fläktlös
sFlow
Strömtillförsel
Ingående ström
3 A
AC-inspänning
100 - 240 V
Växelström Frekvens
50/60 hz
Strömförbrukning (max)
51 W
Strömkälla
AC
Power over Ethernet (PoE)
Typ av PoE (Power over Ethernet) som stöds
PoE+
Total Power over Ethernet (PoE)-budget
370 W
Antal Power over Ethernet plus (PoE +)-portar
24
Power over Ethernet (PoE)-effekt per port
30 W
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Total lagringskapacitet
8 GB
Miljökrav
Fuktighet (förvaring)
5 - 95%
Intervall för relativ operativ luftfuktighet
5 - 90%
Altitud vid drift
0 - 3048 m
Temperatur vid drift
0 - 50 ° C
Temperaturintervall (förvaring)
-40 - 70 ° C
Vikt & dimension
Bredd
441 mm
Djup
258 mm
Höjd
43,4 mm
Vikt
4 kg
Certifikat
Certifikat för överensstämmelse
BSMI, Elektromagnetisk kompatibilitet (EMC), Federal Communications Commission (FCC), RoHS, UL, VCCI
|
Tillbehör |
